Miele PG 8583 - Retrofitting the Large-Surface Filter

161
Intensive
Program header Water volume change[l] Rinse arm monitoring Drainage time On Standard Off for basket Extended Off
Wash block Pre-rinse Main wash Interim rinse Final rinse
Parameter 1 2 3 1 2 1 2 3 4 1 2 Water quality CW50 HW HW DI DI DI
Dosage
1
Dispensing system DOS1 DOS3 Concentration[%] 0.4 0.1
2
Dispensing system Concentration[%]
Wash block temperature 176°F
(80°C)
167°F
(75°C)
Holding time[Min] 1 3 2 1 1 1 Drying Cabinet cooling down time[Min] Drying time[Min]
 =Customizable parameters Min =Holding time in minutes CW HW CWxx DI
=cold water =hot water =CW proportion in mixed water as percentage (CW70 = 70% CW + 30% HW) =aqua destillata, fully demineralized water, DI water
DOS1 DOS3 DOS4
=cleaning agent =neutralizing agent =DOS module
