OM-404 Page 10
3-2. Dimensions, Weights, and Operating Angles
Dimensions
A
Height 31 in (787 mm)
B
C
Width 18-3/4 in (476 mm)
C
Depth 46 in (1164 mm)
D
Do not exceed tilt angles or engine could
be damaged or unit could tip.
A 18 in (457 mm)
G
Do not move or operate unit where it could
tip.
B 16-1/2 in (419 mm)
4 Holes
tip.
C 3/4 in (19 mm)
E
D 3-1/8 in (79 mm)
F
E 32-3/4 in (832 mm)
25°
F 45-1/2 in (1156 mm)
25°
°
G 13/32 in (10 mm) Dia.
25
25°
25
°
Weight
564 lb (256 kg)
800 426
Engine End
3-3. Generator Power Curve
182 719
The generator power curve shows
the generator power in amperes
available at the receptacles.
3-4. Fuel Consumption
SB-145 981
The fuel consumption curve
shows typical fuel use under
weld or power loads.
