Miller FieldPro Remote CE - Page 49

OM-263 657 Page 43
Description
Part
No.
Dia.
Mkgs.
Item
No.
Figure 9-1. Welding Power Source Parts Assembly
Model
Quantit
y
907633
1 257114 Base 1... ................ .. .........................................................
2 265434 Nameplate/Switch Membrane, Front Pnl 1... ............... .. ..........................
3 175138 Box, Louver 1... ............... .. ...................................................
4 170391 Conn, Circ MS Protective Cap 1... ............... .. ...................................
5 254891 Plate, Switch 1... ............... .. ..................................................
6 252839 Panel, Front 1... ............... .. ...................................................
7 268639 Rcpt Assy, Tw Lk Insul Fem(Dinse Type) (Including)2... ............... ..
257995 Rcpt, Tw Lk Insul Fem Dinse Style w/O-ring 1..................... .... .....................
250037 Insulator, Bulkhead Front 1..................... .... ......................................
250039 Insulator, Bulkhead Rear 1..................... .... ......................................
185714 Washer, Tooth 22MMID x 31.5MMOD 1..................... .... ...........................
185717 Nut, M20−1.5 1.00 Hex .19H Brs Locking 1..................... .... ........................
185718 O−Ring, 0.989 ID x 0.070 H 1..................... .... ...................................
186228 O−Ring, 0.739 ID x 0.070 H 1..................... .... ...................................
8 C6 264077 Capacitor Assy 1... ..... ..... .. ................................................
9 254892 Door, SD Reader 1... ............... .. ..............................................
10 234344 Bracket, SD Card Reader 1... ............... .. .......................................
11 PC4 244477 Circuit Card Assy, SD Card 1... ..... ..... .. ......................................
12 PC6 268280 Circuit Card Assy, FC Source Remote Interface (CE) 1... ..... ..... .. ...............
13 FM1 224694 Fan 1... ..... ..... .. ..........................................................
14 176226 Insulator, Switch Power 1... ............... .. .........................................
15 S1 244920 Switch 1... ...... ..... .. ........................................................
253664 Label, On−Off 1..................... .. .................................................
16 225097 Heat Sink, Rect LH 1... ............... .. .............................................
17 211503 Insulator, Heat Sink 1... ................ .. ............................................
18 T1 212132 Xfmr, HF Litz/Litz w/Boost 1... ...... ...... .. .......................................
19 L3 212150 Inductor, Output 1... ...... ...... .. ...............................................
20 212207 Windtunnel, LH 1... ............... .. ................................................
21 196355 Insulator, Screw 4... ............... .. ...............................................
22 D1,D2 201531 Kit, Diode Power Module 2... .... .... .. ........................................
23 199840 Bus Bar, Diode 2... ............... .. ................................................
24 R3/C4 233052 Resistor/Capacitor 1... .... .... .. .............................................
25 SR1 201530 Kit, Diode Fast Recovery Bridge 1... ..... ..... .. .................................
26 RT1,RT2 199798 Thermistor, NTC 30k ohm @ 25 Deg C 18.00 in. 2500V 2... ... ... .. ............
27 HD1 182918 Transducer, Current 400A Module Supply V +/− 15V 1... ..... ..... .. ...............
28 179276 Bushing, Snap−In Nyl 1.000 ID X 1.375 Mtg Hole Cent 3... ............... .. ..............
29 170647 Bushing, Snap−In Nyl 1.312 ID X 1.500 Mtg Hole 1... ............... .. ..................
30 CR1 198549 Relay, Encl 24VDC SPST 35A/300VAC 4pin Flange Mtg 1... ..... ..... .. ...........
31 PC7 255714 Circuit Card Assy, WCC Interface 1... ..... ..... .. ................................
32 252923 Bracket, Mtg WCC Board 1... ............... .. .......................................
33 010546 Bushing, Snap−In Nyl .375 ID X .500 Mtg Hole 1... ............... .. ...................
34 L4 218020 Inductor, Boost 1... ...... ...... .. ................................................
35 227746 Gasket, Inductor Mounting E55 Ferrite Core 1... ............... .. .......................
36 196330 Heat Sink, Power Module 1... ............... .. .......................................
37 L2 218018 Inductor, Pre−Regulator 1... ...... ...... .. .........................................
38 218566 Gasket, Inductor Mounting E70 Ferrite Core 1... ............... .. .......................
39 212206 Windtunnel, RH 1... ............... .. ................................................
40 MOD1,... .... ............
MOD2 261556 Kit, Input/Pre−regulator And Invertor Module 1.... .. .......................
41 153403 Bushing, Snap−In Nyl .750 ID X 1.000 Mtg Hole Cent 2... ............... .. ..............
42 219472 Bracket, Mtg Capacitor Series 1... ............... .. ...................................
43 C15 196143 Capacitor, Polyp Met Film 16. uf 400 VDC 10% 1... ..... ..... .. ....................
+When ordering a component originally displaying a precautionary label, the label should also be ordered.
BE SURE TO PROVIDE MODEL AND SERIAL NUMBER WHEN ORDERING REPLACEMENT PARTS.
