Description
Part
No.
Dia.
Mkgs.
Item
No.
Figure 9-1. Welding Power Source Parts Assembly
(Continued)
Model
Quantit
y
907633
44 PC2 260280 Circuit Card Assy, Interconnect W/Label And Clips 1... ..... ..... .. .................
45 L1 212091 Inductor, Input 1... ...... ...... .. .................................................
46 RM1,... ....
PLG26 205751 Module, Power Resistor W/Plug 1.... .. .................................
47 +252842 Panel, Side 2... .............. .. ...................................................
47 +268254 Panel, Side Red−D−Arc 2... .............. .. .........................................
48 257258 Bracket Upper, Mtg Capacitor/PC Board 1... ............... .. ..........................
49 PC1 256983 Circuit Card Assy, FC Power Source Ctrl Potted 1... ..... ..... .. ...................
50 257260 Bracket, Capacitor Support 1... ............... .. ......................................
51 C12,C13 193738 Capacitor, Elctlt 1800 uf 500 VDC Can 2.52 Dia 2... ... ... .. ....................
52 217040 Nut, Nylon M12 Thread Capacitor Mounting 2... ............... .. .......................
53 FM2 183918 Fan 1... ..... ..... .. ..........................................................
54 252855 Bracket, Mtg Contactors 1... ............... .. ........................................
55 W1,W2 247571 Contactor, Latching (W1 front, W2 rear) 2... ... ... .. ...........................
56 254967 Bus Bar, Input 2... ............... .. .................................................
57 254968 Bus Bar, Output 2... ............... .. ...............................................
58 PC3 252949 Circuit Card Assy, Autoline Cntrl Power 70W Potted 1... ..... ..... .. ................
59 257115 Panel,Rear 1... ................ .. ....................................................
60 182455 Nut, Conduit 1.000 Npt Knurled 1... ............... .. ..................................
61 215980 Bushing, Strain Relief .709/.984 ID x 1.375 Mtg Hole 1... ............... .. ...............
62 252930 Insulator, Rear Panel 1... ............... .. ...........................................
63 257239 Cable, Power 12 ft 8 ga 4c (Non−Stripped End) 1... ............... .. ...................
64 +252841 Cover, Top 1... .............. .. ....................................................
64 +268255 Cover, Top Red−D−Arc 1... .............. .. .........................................
65 256025 Insulator, Side 2... ............... .. .................................................
66 CT1 253320 Xfmr, Current Sensing 200/1 W/15 in. Leads 1... ..... ..... .. .......................
67 219471 Bracket, Mtg Filter Board 1... ............... .. .......................................
68 265141 Circuit Card Assy, Input Filter FieldPro 1... ............... .. ............................
69 148025 Lug,univ W/scr 600V 2/0-6 wire .266 stud 4... ............... .. .........................
70 219473 Bracket,Mtg CE Filter Ground Plane 4... ............... .. ..............................
71 257044 Bracket, Top Extruded 4... ............... .. ..........................................
72 257047 Handle, Carrying Pwxfld 2... ............... .. ........................................
73 257049 Handle, Formed Top 2... ............... .. ............................................
74 257045 Bracket, Side Support 4... ............... .. ..........................................
75 257043 Bracket, Base Extruded 4... ............... .. .........................................
76 PC5 265964 Circuit Card Assy, Frnt Pnl Pwxfld Ps/Rmt w/Pgm VRD 1... ..... ..... .. .............
77 257259 Bracket Lower, Mtg Capacitor/PC Board 1... ............... .. ..........................
78 257382 Bracket, Capacitor Guard 1... ............... .. .......................................
79 257048 Handle, Formed Bottom 2... ............... .. ........................................
80 147139 Tape, Adh Acrylic Double Sided .010 x .500 x 3.000 16... ............... .. ................
81 257050 Bearing, Handle Pwxfld Ps 4... ............... .. ......................................
82 233397 Insulator, Board Bracket Capacitor 1... ............... .. ...............................
83 191944 Capacitor,Polyp Met Film 10. Uf 250 Vac 10% 1... ............... .. .....................
84 194254 Core,Toroidal 22.25mm Id X 36.96mm Od X 15.88mm Th 2... ............... .. ...........
85 259715 Core, Toroidal 28.7mm ID x 43.1mm OD x 18.5mm Th 1... ............... .. ..............
86 241027 Core, Toroidal .748 ID x 1.142 OD x .600 Thk 1... ............... .. ......................
87 224262 Core, Toroidal Nanocrystalline (43.1mm Diameter) 1... ............... .. .................
88 131447 Core, Toroidal 1.332 ID x 1.932 OD x .625 Thk 1... ............... .. .....................
89 255736 Core, Ferrite Emi Snap-on .393 ID x .877 OD x 1.250 thk 3... ............... .. ...........
+When ordering a component originally displaying a precautionary label, the label should also be ordered.
BE SURE TO PROVIDE MODEL AND SERIAL NUMBER WHEN ORDERING REPLACEMENT PARTS
