Technical data
Model
MACSQuant X (# 130-105-100)
Color Green/orange
Footprint (w
×
d) 669 mm
×
368 mm (26.3×14.5")
Footprint with MACSOuant X Orbital Shaker (w
×
d) 814 mm
×
473 mm (32×18.6")
Height (with MACSOuant X Orbital Shaker) 392.5-582 mm (adjustable touchscreen)
Weight 50 kg (110 lbs)
Input voltage 100-240 VAC, 50/60 Hz
Power consumption 450 W
Fuses 2 x 8 AT, 250 V
RS232 Interface
(labeled "RS232/AUX")
Not in use
Pin1, 4, 6-9: NC
Pin 2: RXD
Pin 3: TXD
Pin 5: GND
AC Output
(labeled "Bottle Sensor")
Pin1-5: Input
Pin 6-15: GND
Pin 9-13: Input/Output 5 VAC/10kΩ
RS232 Interface + DC-Output
(labeled "RS232/BCR")
Pin1: Input/Output
Pin 2:TXD
Pin 3: RXD
Pin 4,6: NC
Pin 5: GND
Pin 7, 8: Shorted
Pin 9: 5 VDC/2.6 A
CAN Bus + DC-Output
(labeled "External CAN")
Pin 1, 4, 8: NC
Pin 2: CAN-L
Pin 3, 6: GND
Pin 5,9: 24 VDC/1.85 A
Pin 7: CAN-H
CAN Bus + DC-Output
(labeled "Power CAN")
Pin 1: CAN-L
Pin 2: CAN-H
Pin 3: GND
Pin 5: 24 V DC, 1.1 A
A1: 24 V DC, 5 A
A2: GND
RS232 Interface
(labeled "COM 1")
Pin 1:DCD
Pin 2: RxD
Pin 3: TxD
Pin 4: DTR
Pin 5:GND
Pin 6: DSR
Pin 7:RTS
Pin 8: CTS
Pin 9: RI
9
TECHNICAL DATA AND SPECIFICATIONS
