TECHNICAL DATA AND SPECIFICATIONS
89
Technical data
4 x USB 2.0 ports
(labeled "USB 1-4)"
Pin 1:+5 V
Pin 2:-
Pin 3: +
Pin 4: GND
VGAport
(labeled "VGA")
Video graphics array analog interface supports up
to 2048
×
1536 @75 Hz
Pin 1:RED
Pin 2: GREEN
Pin 3: BLUE
Pin 4: ID2/RES
Pin 5-8, 10: GND
Pin 9: KEY/PWR
Pin 11:ID0/RES
Pin 12: ID1/SDA
Pin 13: HSync
Pin 14: VSync
Pin 15: ID3/SCL
2
×
HDMIports 2
×
High-Definition Multimedia Interfaces support
up to 1920
×
1200 @60 Hz
Pin 1-3:TMDS Data2
Pin 4-6: TMDS Data1
Pin 7-9: TMDS Data0
Pin 10-12: TMDS Clock
Pin 13: CEC
Pin 14: Reserved
Pin 15: SCL
Pin 16: SDA
Pin 17: GND
Pin 18: +5 V/50 mA
Pin 19: Hot Plug detect
2 x Ethernet ports (GbE)
(labeled "LAN 1" and "LAN 2")
Pin1: TXD+
Pin 2:TXD+
Pin 3: RXD+
Pin 4,5,7,8: NC
Pin 6: RXD-
Audio ports Green: headphones
Pink: microphone
CF Card Slot The inserted card contains the operating system of
the MACSQuant Instrument (Microsoft Windows 7
with MACSQuantify Software, read-only mode)
RAM 8 GB DDR4 (SO-DIMM, 1066 MHz)
HDD 2.5" automotive & extended temperature range
Monitor 15.6" HD touchscreen, height-adjustable
Working temperature +15 °C to +25 °C
Humidity 10% to 90% relative humidity, non-condensing
Altitude Max. 2000 m
Emission sound pressure level at workstation < 70 dB(A)
Table 9.1: Technical specifications of the MACSQuant X.
