Parameter Specification
Minimum sample
volume
20 μL (recommended)
Scatter resolution Scatter performance is optimized for resolving human peripheral blood
lymphocytes, monocytes, and granulocytes
Sample flow rate 25-100 μl/min plus automated flow rate to maintain 500, 1000, or 2000
events/second
Maximal event rate Up to 15,000 events/second
Lasers 488 nm, 404 nm, 640 nm
Fluorescence sensitivity
(MESF)
FITC < 150; PE < 100; APC < 150
Absolute cell count
performance
Accuracy +/- 5%; reproducibility (CV) <5%
Sample carryover Typical value of 0.01%
Emission detectors
Channel
FSC
SSC
V1
V2
B1
B2
B3
B4
R1
R2
Filter
488/10 nm
488/10 nm
450/50 nm
525/50 nm
525/50 nm
585/40 nm
655-730 nm
750 nm LP
655-730 nm
750 nm LP
Table 9.2: Operation details of the MACSQuant
®
X.
9.1 EC / EU Declaration of Conformity
This declaration of conformity is issued under the sole responsibility of the manufacturer:
Miltenyi Biotec B.V. & Co. KG
Friedrich-Ebert-Straße 68
51429 Bergisch Gladbach
Germany
This declaration relates exclusively to the machinery in the state in which it was placed on the market, and
excludes components which are added and/or operations carried out subsequently by the final user.
The declaration of conformity refers to the machinery identified as follows:
Description: Laboratory equipment
Model: MACSQuant® Analyzer X
The machinery complies with all essential requirements of the following directives:
2006/42/EC Machinery
2011/65/EU Restriction of the use of certain hazardous substances in electrical & electronic equipment
2014/30/EU Electromagnetic compatibility
9
TECHNICAL DATA AND SPECIFICATIONS
90
