1.1.2 P.1

R.1.1

Maintenance Manual > Operating Principle > Basic Operation > Sub Switch Power ON

Model CJV30/TPC Issued 2008.08.04 Revised 2008.09.17 F/W ver. 1.20 Remark

1.1

Rev.

1.1.2 Sub Switch Power ON

 Indication on LCD

 Processing sequence

Step Processing Description

Indication

on LCD

1 Initial setting of CPU and H/W

2 Display at sub switch power ON 1. [PLEASE WAIT] is displayed.



3 Voltage check 1. Check the power supply voltage on the main PCB assy.

• In the malfunction, [ERROR03 POWER **V] is displayed and the

system goes down.

4 FPGA setting 1. Execute the configuration of PDC and HDC.

• In the malfunction, [ERROR09 FPGA ERROR] is displayed and

the system goes down.

• When the fuse F13 of the main PCB assy is blown, the system shuts

down, displaying [EEROR25 47V HEAD VOLTAGE].

5 Version information display 1. Machine model name and main body firmware version are displayed.

2. “Revision” and “PDC/HDC version” are also displayed during the

service mode.

3. Special key function is workable during the version information is

being displayed. (Except firmware update)





6 Initial operation of the printer 1. Refer to "1.1.3 Initial Machine Operation" .

 Display at sub switch power ON

PLEASE WAIT

 Version information display

CJV30-100 V1.00

 Version information display

(during the service mode)

CJV30-100 V1.00.0

P.1.0.H.1.0

P: PDC, H: HDC
