Maintenance Manual > Test Items > Test Function > [HEATER TEST] SSR
Model CJV30/TPC Issued 2008.08.04 Revised F/W ver. 1.00 Remark
1.0
Rev.
5.1.12 [HEATER TEST] SSR
 Function
ON/OFF test of heater is executed.
 Operation Procedures
Step Item Description Remarks
1 ON/OFF setting Designates ON/OFF of Pre, Print and After Heater. Temperature is not controlled.
2 ON/OFF display [FUNCTION]:Returns to setting screen.
 Temperature is displayed with a unit selected in the [UNIT SETUP] of the [MACHINE SETUP] function.
 A/D conversion value is also displayed.

MIMAKI CJV30 Series Specifications

General

Cutting Function	Yes
Interface	USB 2.0, Ethernet
Power Supply	AC 100-240 V, 50/60 Hz
Print Head	Piezoelectric Inkjet
Resolution	1440 dpi
Print Resolution	Maximum 1440 dpi
Printing Technology	Solvent Inkjet
Print Speed	Up to 17.5 m²/h
Ink Type	Solvent Ink
Ink Colors	CMYK, White
Maximum Print Width	1610 mm (CJV30-160 model)
Media Width	1372 mm (54 inches)
Media Thickness	Maximum 1.0 mm
Cutting Force	500 g
Weight	180 kg (CJV30-160 model)
