Maintenance Manual > Test Items > Test Function > [TEMP.CHECK] HEAT SINK TEMP.
Model CJV30/TPC Issued 2008.08.04 Revised F/W ver. 1.00 Remark
1.0
Rev.
5.1.24 [TEMP.CHECK] HEAT SINK TEMP.
 Function
Temperature of HDC board heat sink is displayed (A/D value is also displayed).
A unit selected in the [UNIT SETUP] of the [MACHINE SETUP] is used in the display of heat sink temperature.
