Maintenance Manual > Test Items > Test Function > [CUT PATTERN] 10m
Model CJV30/TPC Issued 2008.08.04 Revised F/W ver. 1.00 Remark
1.0
Rev.
5.1.38 [CUT PATTERN] 10m
 Function
Cut a test pattern (10 m), and check for slippage, skew, etc. which can occur when a long sheet is fed.
Cutting conditions:
• Speed: 20 cm/s or more
• Pressure: 100 g or less
• Offset: 0.30 mm
(CUT PATTERN 10m)
10 m

MIMAKI CJV30 Series Specifications

General

Cutting Function	Yes
Interface	USB 2.0, Ethernet
Power Supply	AC 100-240 V, 50/60 Hz
Print Head	Piezoelectric Inkjet
Resolution	1440 dpi
Print Resolution	Maximum 1440 dpi
Printing Technology	Solvent Inkjet
Print Speed	Up to 17.5 m²/h
Ink Type	Solvent Ink
Ink Colors	CMYK, White
Maximum Print Width	1610 mm (CJV30-160 model)
Media Width	1372 mm (54 inches)
Media Thickness	Maximum 1.0 mm
Cutting Force	500 g
Weight	180 kg (CJV30-160 model)
