6.5.8 P.2
6.5.8 X-axis Motor Relay PCB Assy
1
2
3
4
5
6
7
8
3. Remove the X-axis motor relay PCB assy.
4. Reverse the disassembly procedure for reassembly.
Screw
X-axis Motor Relay PCB Assy
R.1.0
Maintenance Manual > Disassembly and Reassembly > Electrical Parts > X-axis Motor Relay PCB Assy
Model CJV30/TPC Issued 2008.08.04 Revised 2008.09.17 F/W ver. 1.20 Remark
1.0
Rev.
