Maintenance Manual > Troubleshooting > Details on Errors and Malfunctions > Trouble with No Messages
Model CJV30/TPC Issued 2009.06.30 Revised F/W ver. 1.00 Remark
1.0
Rev.
7.1.4 Trouble with No Messages
 Outline
This explains the troubles where no Error nor Warning messages displays.
 Trouble list
No. Phenomenon Contents or Causes Solution
1 The machine generates strange
noise while operating.
1.

Y belt noise 7.2.1
2. 
X or Y motor hunting
2 The power cannot be turned on
1.

Head, FFC, main PCB, or slider PCB trouble 7.2.3
2. 
The power supply PCB damage
3. 
Poor connection of the connector
3 Abnormal discharging
1. 
Head, FFC, main PCB, or slider PCB trouble 7.2.3
4 Y belt derailment or damage
1.

Y-T pulley tilt 7.2.4

MIMAKI CJV30 Series Specifications

General

Cutting Function	Yes
Interface	USB 2.0, Ethernet
Power Supply	AC 100-240 V, 50/60 Hz
Print Head	Piezoelectric Inkjet
Resolution	1440 dpi
Print Resolution	Maximum 1440 dpi
Printing Technology	Solvent Inkjet
Print Speed	Up to 17.5 m²/h
Ink Type	Solvent Ink
Ink Colors	CMYK, White
Maximum Print Width	1610 mm (CJV30-160 model)
Media Width	1372 mm (54 inches)
Media Thickness	Maximum 1.0 mm
Cutting Force	500 g
Weight	180 kg (CJV30-160 model)
