Maintenance Manual > Operating Principle > Maintenance Function > Maintenance Washing Liquid Filling and Discharge
Model CJV30/TPC Issued 2008.08.04 Revised F/W ver. 1.00 Remark
1.0
Rev.
1.2.8 Maintenance Washing Liquid Filling and Discharge
 Indication on LCD
 Washing liquid filling sequence
 Washing liquid discharge sequence
Step Processing Description
Indication
on LCD
1 Start 1. Insert washing liquid cartridges.
• Filling will not be executed if a warning about the washing liquid cartridge is
displayed. (Monitored with washing liquid cartridge sensors)
• When a waste ink tank warning occurs, the warning message is displayed.
(For details, see "1.2.9 Waste Ink Tank Warning".)

2 Filling 1. Run the pump.
2. Opening the cartridge valve.
(until washing liquid fills the wiper cleaning valve)
3. Close the cartridge valve.
4. Stoppping the pump

Step Processing Description
Indication
on LCD
1 Start 1. Remove the washing liquid cartridges from the printer.
• When a waste ink tank warning occurs, the warning message is displayed.
(For details, see "1.2.9 Waste Ink Tank Warning".)

2 Discharge 1. Run the pump.
2. Opening the cartridge valve.
(until washing liquid fills the wiper cleaning valve)
3. Close the cartridge valve.
4. Stoppping the pump.

Display during maintenance
MaintWashLiquid
FILLING UP START :ent
Display during maintenance
MaintWashLiquid
CARTRIDGE : none
Display during maintenance
MaintWashLiquid
There is a CARTRIDGE
Display during maintenance
MaintWashLiquid
DISCHARGE START :ent
