8.5.1 P.1

R.1.0

Maintenance Manual > Operation Flow > Service Mode > #ADJUST

Model CJV30/TPC Issued 2008.08.04 Revised F/W ver. 1.00 Remark

1.0

Rev.

8.5.1 #ADJUST

#HEAD ADJUST

SLANT ADJUST <ent>

#SLANT ADJUST

PRINT START :ent

#HEAD ADJUST

DROP.POS ADJUST <ent>

#DROP POS. MODE

SELECT :HiSPEED SCAN

#DROP POS. MODE

SELECT :HiSPEED SCAN

:Normal-SCAN

#ADJUST / PRINT

HEAD ADJUST <ent>

#DROP POS. HsHg

SELECT :DRAFT

#DROP POS. HsHg/DRFT

ADJUST :Y Bi

#DROP POS. HsHg/DRFT

Y Bi PRINT :ent

#DROP POS. HsHg

SELECT :FINE

#DROP POS. HsHg/DRFT

ADJUST :FINE-Y Bi

#DROP POS. HsHg/DRFT

FINE-Y Bi PRINT :ent

#DROP POS. HsHg

SELECT :BASIS SET

#DROP POS. HsHg/DRFT

BASIS SET :ent

#HEAD ADJUST

HeadcondCONFIRM<ent>

#HeadcondCONFIRM

INKvolumCONFIRM<ent>

#INKvolumCONFIRM

PRINT START :ent

M= 0 M= 0 C= 0 C= 0

Y= 0 Y= 0 K= 0 K= 0

:-2 to 4

#HeadcondCONFIRM

X POS. CONFIRM <ent>

#HeadcondCONFIRM

Y POS. CONFIRM <ent>

[FUNCTION] / [] / []

[] / []

#X POS. CONFIRM

PRINT START :ent

#Y POS. CONFIRM

PRINT START :ent

[FUNCTION]: All nozzles +1

[REMOTE]: Displays the nozzle row name.

FUNCTION

#ADJUST <ENT>

[] / []

[ENTER] / [END]

#DROP POS. HsHg/DRFT

Y Bi H1 -H1 : 0.0

#DROP POS. HsHg/DRFT

Y Bi H1 -H1 : 0.0

#ADJUST / PRINT

EDGE ADJUST <ent>

[] / []

#EDGE ADJUST

CLEAR < > PRINT

#EDGE ADJUST

L=15.0 R=15.0

#ADJUST / PRINT

500mm SQUARE <ent>

#500mm SQUARE

CLEAR < > PRINT

#500mm SQUARE

X=500.0 Y=500.0

Only at the factory

[]/[]: Modifies the compensation value.

[ENTER]: Finalizes (To the next compensation screen)

Adjustment pattern

drawing

Pattern drawing
