#MOTOR TEST
TAKE-UP MOTOR <ent>
#TAKE-UP MOTOR
RUNNING
#TAKE-UP MOTOR
START :ent
#HEATER TEST
TEMPERATURE <ent>
[FUNCTION] / [] / []
#TEST
HEATER TEST <ent>
[] / []
PRE PRT AFT
35C 35C 35C
35C 35C 35C
(35C 35C 35C)
[] / []
#HEATER TEST
SSR <ent>
<15F> <15F> <15F>
OFF OFF OFF
PRE PRT AFT
35C 35C 35C
#WARMING TEST
OFF [ C] ( 20 C)
#TEST
WARMING TEST <ent>
[] / []
#TEST
ACTION TEST <ent>
#ACTION TEST
VACUUM FAN :LOW
#ACTION TEST
Y-CUTTER :OFF
#ACTION TEST
LED POINTER :OFF
#ACTION TEST
DEOD. FAN :OFF
#ACTION TEST
DRY FAN :OFF
HDC FAN1 : HDC FAN2
ON : ON
#ACTION TEST
PR SOLENOID :OFF
[] / []: Changes items in a loop.
#ACTION TEST
P.HEAD SOLENOID :OFF
#ACTION TEST
VACUUM FAN :LOW
#TEST
SENSOR TEST <ent>
[] / []
#SENSOR TEST
SET LEVER :ON
#SENSOR TEST
R.PAPER :OFF
#SENSOR TEST
Y-ORIGIN :OFF
#SENSOR TEST
WIPER :OFF
#SENSOR TEST
FRONT COVER :ON
#SENSOR TEST
HEAD HEIGHT :OFF
#SENSOR TEST
PR SENSOR :OFF
This screen can be displayed by
pressing [FUNCTION] on any
screen.
#SENSOR TEST
CUT HEAD JOINT :OFF
#SENSOR TEST
PRT.HEAD JOINT :OFF
[JOG]: Changes items in a loop.
The items are displayed in the order shown in Sensor Test Menu. ON = o, OFF = x
L : SET LEVER P : R.PAPER
Y : Y-ORIGIN W : WIPER
H : HEAD HEIGHT PR : PR SENSOR
CJ : CUT HEAD JOINT PJ : PRT.HEAD JOINT
L=o P=o Y=x W=x
H=o PR=x CJ=x PJ=o
#SENSOR TEST
Head Voltage :700
#SENSOR TEST
Main PCB ID :800
#OPTION / REEL = ON
EXH.= ON DRY = ON
#TEST
OPTION <ent>
[] / []
#TEST
KEYBOARD LED <ent>
HEAT:ooo CONST.:ooo
PRINT :o CUT :o
[] / []
#TEST
KEYBOARD TEST <ent>
#KEYBOARD TEST
Key-> NONE
[] / []
#TEST
LCD TEST <ent>
!!!!!!!!!!!!!!!!!!!!
""""""""""""""""""""
#KEYBOARD TEST
Key-> [USER TYPE]
#KEYBOARD TEST
[END]->END TEST
Displayed corresponding to a
pressed key.
[] / []
To Next Page
