Maintenance Manual > Operating Principle > Maintenance Function > Aqua->Sol EXCHG.
Model CJV30/TPC Issued 2009.08.25 Revised F/W ver. 2.00 Remark
1.0
Rev.
1.2.10 Aqua->Sol EXCHG.
 Functional Overview
The function is to replace aqueous pigmented ink with solvent ink on same machine.
Maintenance Open Mode is selectable while filling up aqueous pigmented ink
Menu :> FUNCTION>Maintenance>Aqua->Sol EXCHG.
 Processing Sequence
“DISCHARGE & WASH” + “Initial Filling” performs when starting-up
Solvent ink becomes selectable with “Initial Filling” in this function.
 Requisite for this function
Head cleaning cartridge (cleaning cartridge for aqueous pigmented ink) SPC-188S
Solvent ink filling cartridge SPC-0475
 If normal “Discharge &Wash” is performed while using aqueous pigmented ink,solvent ink is not
selectable when initial ink filling.

MIMAKI CJV30 Series Specifications

General

Cutting Function	Yes
Interface	USB 2.0, Ethernet
Power Supply	AC 100-240 V, 50/60 Hz
Print Head	Piezoelectric Inkjet
Resolution	1440 dpi
Print Resolution	Maximum 1440 dpi
Printing Technology	Solvent Inkjet
Print Speed	Up to 17.5 m²/h
Ink Type	Solvent Ink
Ink Colors	CMYK, White
Maximum Print Width	1610 mm (CJV30-160 model)
Media Width	1372 mm (54 inches)
Media Thickness	Maximum 1.0 mm
Cutting Force	500 g
Weight	180 kg (CJV30-160 model)
