4-4-8. SENSOR TEST
[Function]
The state of the following sensors are checked.
• Medium setting lever sensor • Rear paper presence/absence sensor
• Y-origin sensor • Capping sensor
• Station sensor • Wiper sensor
• Front cover sensorrear • X-origin sensor
• Ink pack sensor • Ink end sensor
[Operation]
1) Select the TEST.
Press the
ENTER
key.
2) Select the “SENSOR TEST” pressing the
FUNCTION
key.
Press the
ENTER
key.
3) The state of the media setting lever is shown
on the LCD.
ON: Lever is in its lower position.
OFF: Lever is in its upper position.
4) Press the
key.
The state of the rear paper sensor is shown on
the LCD.
ON: Medium is present.
OFF: Medium is absent.
5) Press the
key.
The state of the Y-origin sensor is shown on
the LCD.
ON: Origin has been detected.
OFF: Origin has not been detected.
6) Press the
key.
The state of the capping sensor is shown on
the LCD.
ON: The capping has been opened.
OFF: The capping has not been closed.
FUNCTION
# TEST < ENT >
# TEST
SENSOR TEST < ent >
# SENSOR TEST
SET LEVER : OFF
# SENSOR TEST
REAR PAPER : OFF
# SENSOR TEST
Y-ORIGIN : OFF
# SENSOR TEST
CAPPING : OFF
