1-5. Specifications
Item JV4-130 JV4-160 JV4-180
Printing head Method Piezo-electric drop-on demand
Specification Six-heads (3 x 2 lines)
Nozzle High speed plotting : 360 nozzles for each color
Printing speed Two independent plotting : 180 nozzles for each color
Resolution 360, 540, 720, 1440 dpi
Drawing mode Resolution 360 x 360 dpi : 2 / 4 passes, Unidirection / bidirection
Pass 360 x 540 dpi : 3 / 6 passes, Unidirection / bidirection
Printing direction 360 x 720 dpi :4 / 8 passes, Unidirection / bidirection
720 x 720 dpi : 4 / 8 / 16 passes, Unidirection / bidirection
1440 x 720 dpi : 8 / 16 passes, Unidirection / bidirection
1440 x 1440 dpi : 16 / 32 passes, Unidirection / bidirection
Ink type Water-soluble 6 Color (Black, Cyan, Magenta, Yellow) + (Light Cyan, Light Magenta) or
Color pigment ink (Orange, Green)
Water-soluble dye ink
6 Color (Black, Cyan, Magenta, Yellow, Light Cyan, Light Magenta)
Disperse dye ink 6 Color (Black, Cyan, Magenta, Yellow, Light Cyan, Light Magenta)
Delivery system of ink Proprietary system with low ink detection sensor
Capacity of ink cartrige 220 cc ± 5 cc per cartrige
Medium type Glossy medium Grossy white PET, Photo paper, Glossy PVC
Matte medium Mat-PVC, Tarpaulin, Back-lit film
Cloth Nonflamable cloth
Other Artwork film, Canvas, Tarpaulin, Waterproof olefin film, Board
Max. Printing width Width 1371 mm Width 1600 mm Width 1870 mm
Medium size Maximum 1381 mm 1620 mm 1910 mm
(Leaf medium) Minimum 210 mm
Medium size Thickness 1.0 mm or less
(Roll medium)
Roll outside diameter
Ø 150 mm or less
Roll weight 20 Kg or less
Roll inside diameter 2 Inch, 3 Inch
Plotting surface Faces OUT
Roll end treatment Light-adhesive tape is used to allow the paper to be removed from the
core with ease.
Medium size Thickness 7.0 mm or less
(Board) Deflection 1.0 mm or less
Margin Front 85 mm ± 2 mm
(Leaf medium) Rear 85 mm ± 2 mm
Left end 5 mm ± 0.5 mm
Right end 5 mm ± 0.5 mm
Margin Front 50 mm ± 2 mm
(Roll medium) Rear 0 mm ± 0.5 mm
Left end 5 mm ± 0.5 mm
Right end 5 mm ± 0.5 mm
Distance accuracy
Absolute accuracy Whichever the larger one of ± 0.3 mm or ±0.3 % of the designated
Reoroducibility Whichever the larger one of ± 0.2 mm or ±0.1 % of the designated
Perpendecularity ± 0.5 mm / 1000 mm
Medium skew 5 mm or less / 10 m variable
Head height adjustment 1.2 mm to 10 mm variable from the platen surface
Cutting of medium Cutting of Y direction by the head cutter,Cutting accuracy(steps)
0.5mmor less.
Automatic lateral cutting (can be set to ON/OFF), Manual lateral cutting
