– 4.41 –
4-4-6. XY SERVO
[Function]
Continuous outward/inward travel is executed in terms of the X- and Y-direction for the
purpose of durability test.
This test can be executed without placing a media on the plotter.
• Execute the test with speed, acceleration and traveling amount set to the initial val-
ues. If they are excessively increased, the plotter can break.
• In this test, X-axis and Y-axis will not operate simultaneously. And, as for the X-
axis, movement will be only in the paper feed direction rather than reciprocating.
[Operation]
1) Select the TEST.
Press the
ENTER
key.
2) Select the “XY SERVO” pressing the
FUNCTION
key.
Press the
ENTER
key.
3) The screen changes over to permit the setting
of speed and acceleration in the X-direction.
Press the
ENTER
key twice without chang-
ing the set value.
4) The screen changes over to permit the setting
of speed and acceleration in the Y-direction.
Press the
ENTER
key twice without chang-
ing the set value.
5) The screen changes over to permit the setting
of a traveling amount in the X-direction.
Press the
ENTER
key without changing the
set value.
The aging in the X- and Y-direction starts.
6) Press the
key to exit from the
function.
FUNCTION
# TEST < ENT >
# TEST
XY SERVO < ent >
# XY SERVO
X : S = :∗ ∗ ∗ A = ∗ . ∗ ∗
# XY SERVO
Y : S = ∗ ∗ ∗ A = ∗ . ∗ ∗
# XY SERVO
X = ∗ ∗ ∗ Y = ∗ ∗ ∗ ∗
