4-9
Cutting out Data with Register Marks
4
Extended Functions – Cutting –
The Recommended Size of the Area Defined with a Set of Four Register Marks
It is recommended that the size of the area defined with a set of four register marks is in the range of A4 size (210
mm x 297 mm) to A3 size (297 mm x 420 mm).
If you follow this recommendation, you can minimize wasteful spaces and arrange the designs efficiently.
Color of Mark
The mark must be printed in black against the white background.
The register mark will not be detected correctly if the background is not white or the mark is not black.
Mark Blurred
If the mark is blurred, a wrong mark origin can be detected, thus resulting in deviated cutting.
A4 size to A3 size
OK NG
OK
NG
