1-8
Carriage
The carriage consists of the printer unit and the cutter unit.
Printer Unit
Cutter Unit
Conjunct unit
In concert with the data sent from a computer or the movement of the main body,
switching is performed between printer unit and cutter unit.
Printer unit
The printer unit is used for
printing.
Cutter unit
The cutter unit is used for
cutting and printing with a
pen.
Height-adjusting lever
A height-adjusting lever is provided to adjust
the height of the Head in 2 stages according to
the thickness of media. ( P.2-15)
ORIGIN mark
Use the ORIGIN mark as a marker for the origin position when using the printer uni
Tool holder
Attach a tool for cutting media
to the tool holder.
Light pointer
The light pointer is used for detecting the register mark.
Cutter
The cutter is used for cutting off media.
To Next Page
