Cutting with a Dotted Line
4-27
4
Extended Functions – Cutting –
11
Press to select the length of
the part cut out from the medium.
• Set value: 5 to 150mm
12
Press the key.
13
Press the key several times to return to LOCAL.
Reference Value
The followings are the cutting condition and dotted line cutting condition when cutting the cutting sheet or the
polyvinyl chloride media.
The followings are the cutting condition and dotted line cutting condition when cutting 65 kB (kilogram base)
media.
• When a tool condition other than "HALF" has been selected in Step 4, cutting with a dotted line cannot
be set.
• The set values are recorded even when the power has been turned OFF.
• When a medium is cut with a dotted line, the medium is cut along with the backing sheet. Therefore, the
life of a cutter blade is shorter than in normal cutting.
• The cutting pressure applied when a medium is cut through can be set by cutting conditions ( P.2-3).
Cutting condition
Condition for cutting
with a dotted line
PRESSURE 100 ~ 150 g HALF CUT PRES. 30 g
OFFSET 0.30 mm HALF LENGTH 0.5 mm
CUT LENGTH 10 mm
Cutting condition
Condition for cutting
with a dotted line
SPEED 40 cm/s HALF CUT PRES. 0 g
PRESSURE 40 g HALF LENGTH 0.5 mm
OFFSET 0.30 mm CUT LENGTH 10 mm
• "CUT LENGTH" needs to be set shorter for characters with many strokes and small characters.
[CUT1]HALF CUT
CUT LENGTH = 5 0mm
To Next Page
