14 - 4 Defibrillator/Monitor Operator’s Manual
To manually start a zero calibration:
1. Press the Main Menu button on the front panel, and then select [Others >>] → [Maintenance >>] →
[Installation Mode >>] → enter the required password.
2. Select [Maintain CO2] → [Zero].
Disconnecting the patient airway is not required when performing a zero calibration.
• The CO
2
module temporally stops measuring during zeroing.
14.6 Changing CO
2
Settings
14.6.1 Changing CO
2
Alarm Settings
1. Select the CO
2
parameter area to enter the [CO2 Setup] menu.
2. Select [Para. Alarm >>]
3. Set the following alarm properties:
â—† Switch on or switch off the alarms or alarm recording.
â—† Adjust the alarm limits or alarm priority.
14.6.2 Setting Pressure Unit
1. Pr
ess the Main Menu button on the front panel, and then select [Others >>] → [Configuration >>] →
enter the required password.
2. Select [CO2 Setup].
3. Set [Press. Unit].
14.6.3 Changing CO
2
Wave Settings
1. Select the CO
2
parameter area to enter the [CO2 Setup] menu.
2. Set the wave sweep and scale.
â—† Select [Sweep] and then choose an appropriate setting. The faster the wave sweeps, the wider the
wave is.
â—† Select [Scale] and adjust the upper scale to change the amplitude of CO
2
waveform.
3. Select [Others >>] and set the wave type:
â—† [Draw]: The CO
2
wave is displayed as a curved line.
â—† [Fill]: The CO
2
wave is displayed as a filled area.
14.6.4 Changing CO
2
Operating Mode
To change CO
2
operating mode:
1. Select the CO
2
parameter area to enter the [CO2 Setup] menu
2. Set [Operating Mode].
â—† [Measure]: only in the Measure mode can you start the CO
2
module.
â—† [Standby]: in the standby mode, the gas intake pump, infrared light source, etc. are automatically
switched off to reduce power consumption and extend the lifetime of the CO
2
module.
