Defibrillator/Monitor Operator’s Manual 21 - 11
21.6.12 Alarm Setup Menu
21.6.13 Waveform Setup Menu
Menu Item Options/Range Default Description
Alarm Pause Time 1, 2, 3, 5, 10, 15 min,
Permanent
2 min Sets the alarm pause time.
Audio Off Enabled, Disabled Disabled Sets whether the audible alarm
tones are turned off.
Alm Volume • [Audio Off] is enabled: 0
to 10.
•[Audio Off] is disabled: 1
to 10.
2 Sets the alarm volume level.
Reminder Tone On, Off Off Sets whether the equipment
gives a reminder tone when
alarm or alarm sounds are
turned off.
Reminder Volume High, Med, Low Med Sets the reminder tone volume.
Latching Alarms Yes, No No Sets how alarm indicators
behave if you do not reset the
physiological alarms.
Displaying Alarm Limits Yes, No Yes Sets whether to display the
alarm limits.
ECGLeadOff Lev. High, Med, Low Low Sets the alarm level for “ECG
Lead Off”.
SpO2SensorOff Lev. High, Med, Low Low Sets the alarm level for “SpO2
Sensor Off”.
No Battery Status Indicator On, Status
Indicator Off
Status Indicator
On
Sets how the status indicator
behaves if no battery is
installed.
Alarm Tone
Interval
High Level
Alarm (s)
3 to 15s 10s Sets the interval between alarm
tones.
Med Level
Alarm (s)
3 to 30s 20s
Low Level
Alarm (s)
16 to 30s 20s
Menu Item Options Default Description
Wave 1 / ECG1 ECG1 Unchangeable
Wave 2 3-Lead Pleth, CO2, Resp Pleth For optional parameters,
options of waveforms are
available only when the
parameters are configured.
5-Lead ECG2, Pleth, CO2,
Resp
ECG2
Wave 3 3-Lead Pleth, CO2, Resp CO2
5-Lead Pleth
CO2 Wave Type Draw, Fill Draw Set the CO
2
waveform type.
Parameter/
Wave Color
ECG Green, Yellow, Cyan, White, Red,
Blue, Purple, Orange
Green Sets the parameter color.
Resp Yellow
SpO2 Cyan
NIBP White
CO2 Yellow
To Next Page
