Defibrillator/Monitor Operator’s Manual 20 - 1
20 Network Connection
20.1 Network Introduction
The equipment supports the network function. The equipment can send real-time data to the CMS through
wired and wireless networks or send HL7 messages.
20.2 General Network Settings
20.2.1 Selecting a Network Type
1. Press the Main Menu button on the front panel, and select [Others >>] → [Configuration >>] → enter the
required password.
2. Select [Network Setup] and set [Network Type] to [LAN] or [WLAN].
3. Set [Address Type].
◆ [DHCP]: the equipment can automatically acquire network parameters.
◆ [Manual]: you need to manually input the IP address, subnet mask and gateway address.
4. Select [Return].
20.2.2 Storing Preset Sites
You can store up to 2 preset sites which can be selected in the drop-down list once successfully stored.
1. Press the Main Menu button on the front panel, and select [Others >>] → [Configuration >>] → enter the
required password.
2. Select [Network Setup].
3. Set [Site Setup].
◆ [Select Site]: select a site number in the drop-down list.
◆ [Site Name]: manually input the name of the target CMS.
◆ [Site Address]: manually input the IP address or domain name to specify the target CMS.
4. Select [Return].
20.2.3 Setting DNS
You can set DNS for connecting the CMS and server using domain name.
To set DNS:
1. Press the Main Menu button on the front panel, and select [Others >>] → [Configuration >>] → enter the
required password.
2. Select [Network Setup].
3. Set [DNS Address Type].
◆ [Manual]: the address of the DNS server must be manually entered.
◆ [DHCP]: the equipment will automatically acquire the address of the DNS server. This is only available
when [Address Type] is set to [DHCP] in the [Network Setup] menu.
4. If [Manual] was selected in Step 3, set [Preferred DNS Server] and [Alternate DNS Server].
