A - 4 Defibrillator/Monitor Operator’s Manual
• The equipment startup time in the fast startup mode is less than 2s.
Impedance
Selected energy
25Ω 50Ω 75Ω 100Ω 125Ω 150Ω 175Ω Accuracy
1 J 1110.90.90.90.8±2J
2 J 2221.91.81.71.6±2J
3 J 2.9 3 2.9 2.8 2.7 2.6 2.4 ±2J
4 J 3.9 4 3.9 3.7 3.6 3.4 3.2 ±2J
5 J 4.9 5 4.9 4.7 4.5 4.3 4.1 ±2J
6 J 5.8 6 5.8 5.6 5.3 5.1 4.9 ±2J
7 J 6.8 7 6.8 6.6 6.3 6 5.7 ±2J
8 J 7.8 8 7.8 7.4 7.1 6.8 6.5 ±2J
9 J 8.8 9 8.8 8.4 8 7.7 7.3 ±2J
10 J 9.7 10 9.7 9.3 8.9 8.5 8.1 ±2J
15 J 15151514131312±15%
20 J 20202019181716±15%
30 J 29302928272524±15%
50 J 49504947454341±15%
70 J 68706865626057±15%
100 J 97 100 97 93 89 85 81 ±15%
150 J 146 150 146 140 134 128 122 ±15%
170 J 166 170 166 159 151 145 138 ±15%
200 J 195 200 195 187 178 170 163 ±15%
300 J 292 300 292 280 267 255 244 ±15%
360 J 351 360 350 336 321 306 293 ±15%
Charge time (Note: at 20 ±5 °C of ambient temperature)
Manual Defib AED
Charge time From initial
power on (from
cold start) to
charge done
From initial
power on (from
fast startup
mode) to charge
done
From initiation
of rhythm
analysis to
charge done
From initial
power on (from
cold start) to
charge done
From initial
power on (from
fast startup
mode) to charge
done
200J 360J 200J 360J 200J 360J 200J 360J 200J 360J 200J 360J
With a new, fully
charged battery
<3 s <7 s <11 s <14 s <6 s <10 s <10 s <12 s <21 s <26 s <13 s <15 s
With a new, fully
charged battery,
depleted by 15 360 J
discharges
<4 s <8 s <12 s <15 s <7 s <11 s <11 s <13 s <23 s <27 s <14 s <16 s
With 90% to 100%
rated mains voltage
<4 s <7 s <11 s <14 s <7 s <10 s <11 s <12 s <22 s <24 s <14 s <15 s
