Mindray DC-8 EXP Service Manual

11-16 System Diagnosis and Support
Fig 11-6 Test result screen
9. When self-test is finished, click [Test Report Save Location], select [Save Result] to save the
results, and then click [Shut Down] to shut down the system.
Item
Meaning
Test Report
Save Location
check box
Displays all the removable storage media connected to the system (e.g., USB
disk, removable hard disk), the check box can’t be selected during the test.
If there is no storage media, click the check box, the system will ask the user to
insert storage media.
Save Result
button
Save the test data to the selected directory, the button can’t be used during the
test or if no storage media is selected.
Shut Down
button
Close the program, and shut down the system. If the test report is not saved, the
system will ask the user if to save the report to storage media.
