Mindray DC-8 EXP User Manual

Cardiology 6-11
Types Tools Descriptions Methods or formulae
MV ARa(lateral) Mitral Valve lateral Acceleration Rate
MV DRa(lateral)
Mitral Valve lateral Deceleration
Rate
Calculation / /
Study See below
6.4 Cardiac Measurement Operations
Tips: 1. See the table in "6.3 Cardiac Measurement Tools" above for measurement tools and
methods.
2. For the definitions of measurement, calculation and study, refer to "1.3
Measurement, Calculation and Study".
3. The order of the measurement items is presettable, see "2.4.2 Application
Measurement Preset" for details.
4. A measurement tool can be activated by clicking the item either in the measurement
menu or touch screen menu, it is described as "Select/Click ...(certain item) in the
measurement menu" in the following procedures.
5. Measurements of some tools described in this Chapter are to be performed in
several imaging modes, please select appropriate imaging modes before
measurement.
6.4.1 Measurement Tool Operations
1. Select the item/tool in the measurement menu.
2. Perform the measurement referring to methods in table above.
6.4.2 Calculation Tool Operations
1. Select the item/tool in the measurement menu.
2. The system calculates and displays the results after relating measurement items have been
completed.
6.4.3 Study Tool Operations
6.4.3.1 Left Ventricular Function
This group of studies is to estimates the Left Ventricular (LV) diastolic and systolic capabilities by a
series of clinical indices measured on B or M image. Except for calculating left ventricular volume
and end diastole and end systole, they may calculate the following indices (not all indices are
calculated in every study, see Study Results table in each study for reference).
Result Descriptions Formulae
SV Stroke Volume SV(ml) = EDV(ml)-ESV(ml)
CO Cardiac Output CO(l/min) = SV(ml)×HR(bpm)/ 1000
EF Ejection Fraction EF(No unit) = SV(ml)/ EDV(ml)
SI SV Index SI(No unit) = SV(ml)/ Body Surface Area (m
2
)
CI Cardiac output CI(No unit) = CO(l/min)/Body Surface Area (m
2
)
