Measure Preset 2-13
Attributes Descriptions
Item Name &
Result
Results obtained from D trace are listed. The selected items will be displayed in
the result window.
If PV is selected, other results become deselected (except the temporary
result “velocity”).
Some results such as PS and ED can derived via simply method (e.g.
Velocity); but others such as TAMAX can only derived via complicated
method like Manual, Spline, Auto etc.
z Only Vel in the [Method] is available if only PS or ED is selected.
z Only 2 PT in the [Method] is available if both PS and ED are selected
(with others deselected).
z More complicated methods to obtain PS and TAMAX simultaneously
are available if both PS and TAMAX are selected.
Unit Select the measurement unit.
Meas Method Select the measurement method for the tool.
c) Click [OK] to confirm the setting.
7. Select the measure sequence.
h [Repeat]: after the current measurement is completed, the system automatically
activates the current tool again.
h [Next]: after the current measurement is completed, the system automatically
activates the next tool in the menu.
h [None]: after the current measurement is completed, the cursor can be moved on the
whole screen. And the cursor will automatically return to the menu of the
corresponding measurement.
8. Click [Save] to confirm.
2.4.2 Application Measurement Preset
2.4.2.1 Basic Procedures
1. Select the [Measure] in the [Measure Preset] page. As shown in figure below.
