Cardiology 6-15
Bullet
 Study Items
Tools Descriptions Operations
LVLd apical
Left Ventricular Long-axis Length at End-
diastole in apical view
Distance in 2D General
Measurements
LVLs apical
Left Ventricular Long-axis Length at End-
systole in apical view
LVAd sax MV
Left Ventricular Area at Mitral Valve level at
End-diastole in Short-axis view
Area in 2D General
Measurements
LVAs sax MV
Left Ventricular Area at Mitral Valve level at
End-systole in Short-axis view
HR Heart Rate
Obtained by ECG or input
directly
 Study Results
Tools Descriptions Formulae
EDV(Bullet)
End-diastolic Left
Ventricular Volume
EDV(ml)= 5/6×LVLd apical(cm)×LVAd sax MV(cm
2
)
ESV(Bullet)
End-systolic Left
Ventricular Volume
ESV(ml)= 5/6×LVLs apical(cm)×LVAs sax MV(cm
2
)
EDV Index(Bullet)
End-diastolic Left
Ventricular Volume
Index
EDV Index=EDV/BSA
ESV Index(Bullet)
End-systolic Left
Ventricular Volume
Index
ESV Index=ESV/BSA
SV(Bullet) Stroke Volume
See table in "6.4.3.1 Left Ventricular Function"
CO(Bullet) Cardiac Output
EF(Bullet) Ejection Fraction
SI(Bullet) SV Index
CI(Bullet) CO Index
 Operating Procedures
1. Select [Bullet] in the measurement menu.
In apical long-axis view, measure the following parameters:
At end diastole: LVLd apical
At end systole: LVLs apical.
2. In short-axis view at mitral valve level, ，measure the following parameters:
At end diastole: LVAd sax MV, the EDV is calculated
At end systole: LVAs sax MV, the ESV is calculated
The system calculates SV and EF; If height and weight have been input already, SI, EDV
Index and ESV Index are calculated.
3. Using touch screen knob to select HR source: ECG or input.
The CO and CI are calculated automatically.
