2. In apical two-chamber view, measure the following parameters:
Left ventricular endocardium at end-diastolic, and set the long axis, the EDV(A2C) is obtained;
Left ventricular endocardium at end-systolic, and set the long axis, the ESV(A2C) is obtained;
3. In apical four-chamber view, measure the following parameters:
Left ventricular endocardium at end-diastolic, and set the long axis, the EDV(A4C) is obtained;
Left ventricular endocardium at end-systolic, and set the long axis, the ESV(A4C) is obtained;
4. If height and weight have been input already, SV, EF, SI, EDV Index and ESV Index are
calculated.
5. Using touch screen knob to select HR source: ECG or input.
The CO and CI are calculated automatically.
Cube
 Study Items
Tools Descriptions Operations
Diastole
End-diastolic Left Ventricular
Measurement
FoldLine in 2D mode
Parallel method in M mode
Systole
End-systolic Left Ventricular
Measurement
LVIDd
Left Ventricular Internal Diameter
at End-diastole
Distance in 2D/M General
Measurements
LVIDs
Left Ventricular Internal Diameter
at End-systole
HR Heart Rate
Obtained by ECG, input directly or
measure manually
 Study Results
Tools Descriptions Formulae
IVSd
Interventricular Septal Thickness at End-
diastole
Distance in 2D/M General
Measurements
LVPWd
Left Ventricular Posterior Wall Thickness at
End-diastole
IVSs
Interventricular Septal Thickness at End-
systole
LVPWs
Left Ventricular Posterior Wall Thickness at
End-systole
EDV(Cube) End-diastolic Left Ventricular Volume EDV(ml)= LVIDd(cm)
3
ESV(Cube) End-systolic Left Ventricular Volume ESV(ml)= LVIDs(cm)
3
EDV
Index(Cube)
End-diastolic Left Ventricular Volume EDV Index=EDV/BSA
ESV Index(Cube) End-systolic Left Ventricular Volume ESV Index=ESV/BSA
SV(Cube) Stroke Volume
See table in “6.4.3.1 Left
Ventricular Function”
CO(Cube) Cardiac Output
