Mindray DC-8 EXP User Manual

Cardiology 6-33
Tools Descriptions Formulae
MR Flow
Rate
Mitral Regurgitation
Flow Rate
/s)Als.Vel(cm MRRad(cm) MR2Rate(ml/s) Flow MR
2
×= π
MR Fraction
Mitral Valve
Regurgitation
Fraction
%100
SV(ml)MV
Flow(ml) MR
(Nounit) Fraction MR ×=
MR EROA
Mitral Valve
Effective
Regurgitant Orifice
Area
Vmax(cm/s) MR
/s)Als.Vel(cm MRRad(cm) MR2
EROA(cm) MR
2
2
×
=
π
 Operating Procedures
1. Enter color mode, adjust the color map until the aliasing appears.
2. Select [PISA MR] in the measurement menu.
3. Measure MR Rad using PISA caliper.
Input MR Als.Vel.
4. Measure the MR spectrum by D trace to obtain:
MR Vmax
MR VTI
MR Flow, MR Flow Rate and MR EROAare calculated automatically.
If MV SV is measured, MR Fraction will be calculated automatically.
PISA AR
Aortic valve regurgitation (PISA AR) needs to be measured in Color and Doppler mode.
 Study Items
Tools Descriptions Operations
AR Rad Aortic Valve Stenosis Radius PISA measurement
AR VTI
Aortic Valve Regurgitation
Velocity-Time Integral
D Trace in Doppler General Measurements
AR Als.Vel
Aortic Valve Regurgitation
Aliasing Maximum Velocity
You can select to use top aliasing velocity or
bottom aliasing velocity or input the value
directly.
 Study Results
Tools Descriptions Formulae
AR Vmax
Aortic Regurgitation
Maximum Velocity
Obtained from AR VTI measurement
AR Flow
Aortic Regurgitation
Flow
VTI(cm) AR
max(cm/s) ARV
/s)Als.Vel(cm ARRad(cm) AR2
Flow(ml) AR
2
×
×
=
π
AR Flow
Rate
Aortic Regurgitation
Flow Rate
/s)Als.Vel(cm ARRad(cm) AR2Rate(ml/s) Flow AR
2
×= π
AR Fraction
Aortic Valve
Regurgitation
Fraction
%100
SV(ml)AV
Flow(ml) AR
(Nounit) Fraction AR ×=
