Chapter 3 Product Specifications
27
3.3 Power Source Specifications
AC mains
Input voltage 100 to 240V
Frequency 50/60Hz
Power 140VA
DC mains
Input voltage 10 to 16VDC（rating-12 VDC）
Power 80W
Internal battery
Number of batteries 1
Type Sealed lead-acid battery or lithium-ion battery
Time to shutdown 5 to 15min (after the first low-power alarm)
Sealed lead-acid battery
Nominal voltage 12VDC
Capacity 2.3Ah
Operating time
75 minutes typical when powered by one new fully-charged
battery (25℃, ECG, SpO2, NIBP measurement per 15 minutes).
Charge time About 8 h (in the running status or standby mode)
Lithium battery
Rated voltage 11.1VDC
Capacity 4.4Ah
Operating time
150 minutes typical when powered by one new fully-charged
battery (25℃, ECG, SpO2, NIBP measurement per 15 minutes).
Charge time About 8 h (in the running status or standby mode)
