Chapter 4 Disassembling/Assembling & Troubleshooting
49
10 9300-20-13901 Backlight insulation plate 1
11 8000-20-10214 IBP insulation plate 1
12 M03A-30-26050 CO/IBP board 1
13 7000-20-24418 Insulation plate for main board 1
14 7000-30-24425 Battery rack assembly 1
15 7000-30-24424 Socket assembly 1
16 DA8K-20-14426 SPO2 mount 1
17 9006-30-33900 9006 SPO2 board 1
18 812A-30-08569 812A ECG board assembly 1
19 M04-060009---
Bolt M3×14
3
20 7001-20-67403 CO
2
module mounting board 1
21 7000-20-24509 Insulation plate for ECG board 1
22 M04-051121---
Cross head screw M2.5×8
4
23 M90-000002--- Insulation flat washer 4
24 M02A-30-25930 CO
2
module 1
25 0000-10-11002 Wireless network card 1
26 9201-30-35920 CF card interface board 1
27 7001-30-67468 Flexible cable for CF card 1
28 M04-002505---
Cross head screw M3×6
4
29 7001-30-67454 Power socket assembly 1
30 M04-021024--- Washer 3
31 M04-003012---
Cross head screw M3×6
39
32 9200-21-10442 Backlight board connecting wire 1
33 8000-21-10141 Power cord for DC/DC converter 1
34 7001-30-67438 Lead acid battery power board 1
35 7000-20-24387 Power board insulation sheet 1
36 7001-20-67470 Power board mount 1
37 9210-30-30150 Main board 1
38 9901-10-23920 Conducting pad 0.1m
39 7000-20-24365 Battery latch 1
40 7000-20-24420 Screw for fixing battery latch 1
41 7000-20-24366 Main support 1
42 M04-030031---
Hex bolt M3×20
1
43 M04-000603--- Lock washer 1
44 M04-000306---
Bolt M3×16
1
45 630D-30-09111 630D PCB assembly 1
46 A21-000009--- Hose 0.4m
47 7000-20-24539 Screen support 1 for LG screen 1
48 7000-20-24446 Keypad connecting wire 1
49 7000-20-24447 Net twine 1
50 9200-21-10446 Communication wire to ECG/TEMP/RESP
board
1
51 7000-20-24442 Communication wire to SPO
2
board 1
