Service Manual Combics
Expanded View Diagram 2
Refer to the spare parts list in ISSS.
PCBs for Combics
201 Main PCB (on board ADU 2 x 3000e),
For Combics 1, DSUB, IP44
or
202 Main PCB (on board ADU 2 x 3000e),
For Combics 1, clamping connectors, IP69K
or
203 Digital PCB (without ADC), DSUB, IP44
For Combics 1, 2, 3 with options:
A6, A62, A7, A72, A8, A10
or
204 Digital PCB (without ADC), IP69K
clamping connectors, for Combics 1, 2, 3
With options: A6, A7, A8, A10
205 Alibi memory (option E5)
206 ADC PCB, 10.000e (option A10/A20)
207 ADC PCB for Combics 2 and 3
(2 x 3000e)
208 RS-232 interface PCB
(option A6/A7 or A62/A72)
209 Power supply module
15V 530 mA DC
15V 800 mA DC
Compact line 24V for power supply PCB
(option L8)
203/204
201/202
205
205
206
208
207
209
209
