Minebea Intec Combics Series User Manual

95
Service Manual Combics
Adjustment data
38
GWT-TEDEA_12.12.06.xls
Load Cell Connection (Color Assignments)
Adjusting the Weighing Platform
Load cell
manufacturer
Wägezellen
Hersteller
+Excitation/
+Supply/
+Eingang
-Excitation/
-Supply/
-Eingang
+Signal/
+Ausgang
+Output
-Signal/
-Ausgang
-Output
+Sense -Sense
Cable construction
Anmerkung zur
Kabelausführung
Sartorius Hamburg
red blue green gray white black
(z.B.: MP58T/...)
rot blau grün grau weiß schwarz
Combics (011...)
blue black white red green gray
blau schwarz weiß rot grün grau
TEDEA 1510
green black red white blue brown
grün schwarz rot weiß blau braun
d 5mm, 6 wires,
green
,
shield grounded
d 5mm, 6 adrig, grün,
Abschirmung geerdet
d 5mm, 6 wires,
green
,
shield grounded
d 5mm, 6 adrig, grün,
Abschirmung geerdet
Bridge supply voltage
Brückenspeisespannung
Test voltage
Messspannung
