Bytes 063
Name Type of data Function
Byte 3 Material ID BYTE
Value range: 110
Byte 47
Set point DINT/REAL Weight
Byte 811
Preset DINT/REAL Preset point for switching from coarse ow
to ne ow.
Byte 1215
Material overshoot (OVS) DINT/REAL Weight
Byte 1619
Calming time DINT [ms]
Byte 2023
Tolerance above set point DINT/REAL Weight
Byte 2427
Tolerance below set point DINT/REAL Weight
12.3.5.2 Read window EasyFill → PLC
The data required for monitoring and controlling lling does not t in a 64-byte write
window. For this reason the system dierentiates between system and material
parameters. The value of the rst byte can be used to determine whether the data refers
to the system or the material.
12.3.5.2.1 System data
Before starting lling, a check must be carried out to ensure that the system is ready
(byte 3: bit 2).
The Dosing_Run bit is set once lling has successfully started.
Bytes 063
Name Type of data Function
Byte 0 TableSelect USINT Content of read data:
0 = system data, 1 = material data
Byte 1
Bit 0: MSB
Bit 0: ADC error
Bit 1: above max. + still permis-
sible range (OVL)
Bit 2: above max. (FSD)
Bit 3: below zero
Bit 4: zero ±¼ d
Bit 5: within zero set range (ZSR)
Bit 6: weight is stable
Bit 7: weight above max. (FSD)
and below overload
BOOL
Transmitter Series PR 5220 12 Fieldbus interface
Minebea Intec EN-206
