28
Front Panel Menu Operation
5.1.8 CO Report
This report shows which CO devices need to be replaced.
Step 3: Select a node, card, and loop
1. Use and to scroll through the
numbers.
2. Select the node number, then press .
3. Select the card number, then press .
4. Select the loop number, then press .
• You can also choose all nodes, all cards, or all
loops by selecting ALL.
An example of the information displayed on screen is
shown on the left.
The second and third line pinpoint the exact device.
Below that is the present obscuration percentage of the
device.
Step 1: Select CO
1. Use and to scroll the cursor to “CO
Report”.
2. Press to select the CO Report submenu.
Step 2: Print or view CO
• To print the CO report to the printer, press
when the cursor flashes beside “Printer”. Go to
Step 3.
• To view the CO log on the screen, press
then to select “Screen”. Go to Step 3.
Select Node, Card
& Loop
Node:ALL
Node 1 Card 1 Lp 1
01-01-011N-S001.001
(CLIP)1251 Ion Det
Current Osbc: 0.00%
- Reports Menu -
6 Maint. Report
7 Obscuration
8 CO Report
- Report to -
1 Printer
2 Screen
To Next Page
