36
Front Panel Menu Operation
At this point the display varies, depending on your choice:
• If you selected “yes”, the display shows either the message “Loop bypassed” or “Loop
unbypassed”, then it returns to the Command Menu.
• If you selected “no”, the display shows the message “Operation cancelled”, then it
returns to the Command Menu.
5.2.5 Relay Disc
This option is useful if you want to disconnect the common auxiliary relays.
At this point the display varies, depending on your choice:
• If you selected “yes”, the display shows either the message “Common aux relays now
disconnected” or “Relays reconnected”, then it returns to the Command Menu.
• If you selected “no”, the display shows the message “Operation cancelled”, then it
returns to the Command Menu.
5.2.6 Input Zone
Use this option if you want to bypass an entire zone of addressable devices from the panel.
Usually this is done during building maintenance.
To unbypass the input zone, follow the same procedures for input zone bypass.
Step 1: Select Input Zone Bypass
1. Use and to scroll to “Relay Disc”.
2. Press to continue.
Step 2: Disconnect the relays
The system asks whether or not you want to
connect or disconnect the auxiliary relays.
1. Use and to select “yes” or “no”.
2. Press to continue.
Warning: Bypassing an input zone disables all input devices in that zone.
Step 1: Select Input Zone Bypass
1. Use and to scroll to “Input Zone”.
2. Press to continue.
- Bypass Menu -
2 Node
3 Loop
4 Relay Disc
Common aux relays
currently connected.
Disconnect?Y
- Bypass Menu -
3 Loop
4 Relay Disc
5 Input Zone
To Next Page
