39
Front Panel Menu Operation
5.2.9 Node Outputs
This option is useful if you want to bypass all the outputs of a node. To unbypass the outputs of
a node, follow the same procedures for Node Outputs bypass.
At this point the display varies, depending on your choice:
• If you selected “yes”, the display shows either the message “Zone bypassed” or “Zone
unbypassed”, then it returns to the Command Menu. There is a trouble for each output
that is bypassed.
• If you selected “no”, the display shows the message “Operation cancelled”, then it
returns to the Command Menu.
5.2.10 Positive Alarm Sequence
This option is useful if you want to bypass the positive alarm sequence (PAS). This option is
available only if it is enabled in the configuration.
Step 1: Select Node Outputs Bypass
1. Use and to scroll to “Node Outputs”.
2. Press to continue.
Step 2: Select a node
1. Use and to select the node number.
2. Press to continue.
Step 3: Select “yes” or “no”
The system asks whether or not you want to bypass or
unbypass the node outputs.
1. Use and to select “yes” or “no”.
2. Press to continue.
Step 1: Select Input Zone Bypass
1. Use and to scroll to “Pos. Alm. Seq”.
2. Press to continue.
- Bypass Menu -
5 Input Zone
6 Output Zone
7 Node Outputs
- Bypass Menu -
6 Output Zone
7 Node Outputs
8 Pos. Alm. Seq
To Next Page
