Instructions for Use SonaStar Ultrasonic Surgical Aspiration System
IFU-601 Rev T March 2023 Page 45 of 73
9. Pull taut the large diameter portion of the silicone irrigation tubing (with yellow stripe) that
attaches to the IV line. Route clockwise around the irrigation pump head (see Figure 6-2),
following the direction indicated with the IV spike at the top. While keeping the tubing taut,
shut the gate of the pump. The flow of solution will be clockwise around the pump head.
Incorrect routing of irrig
ation tubing will result in no flo
solution to the tip; this may cause damage to handpiece.
Figure 6-2: Routing of Irrigation Tubing
10. Remove the protective cap from the IV spike and spike the IV bag to attach the
administration set to the IV bag and flush the IV tubing, taking care to maintain sterility. Open
the roller clamp all the way.
11. Position wireless footswitch as desired by surgeon. The footswitch may be placed in a clear
plastic bag to keep clean.
Figure 6-1: Open Irrigation Pump Gate
