Instructions for Use SonaStar

Ultrasonic Surgical Aspiration System

IFU-601 Rev T March 2023 Page 69 of 73

10.3 Fuse Requirements

100/110/115/120 VAC Syste ms

Fuse Fuse Type

Fuse

Rating

LITTLEFUSE

Part Number

Location on Rear

of Console

Relevant

Figures

5x20 mm

Fast-Acting

6.3A, 250V 021706.3 Bottom 4-5 and 4-6

5x20 mm

Fast

Acting

6.3A, 250V 021706.3 Bottom 4-5 and 4-6

3AG

Fast-Acting

5A, 250V 312005

Top

4-5 and 4-6

200/220 /230/240 VAC Systems

Fuse Fuse Type

Fuse

Rating

LITTLEFUSE

Part Number

Location on Rear

of Console

Relevant

Figures

5x20 mm

Time Delay

3.0A, 250V 0239003 Bottom 4-5 and 4-6

5x20 mm

Time Delay

3.0A, 250V 0239003 Bottom 4-5 and 4-6

3AG Fast-

Acting

5A, 250V 312005

Top

4-5 and 4-6

10.4 UL (IEC) 60601-1 Classification

Class I Equipment

Type B Equipment

Ordinary Equipment
