Instructions for Use SonaStar Ultrasonic Surgical Aspiration System
IFU-601 Rev T March 2023 Page 33 of 73
4.4 Wireless Indicators
1. LED Indicator “Replace Footswitch Battery” (Solid red)
2. LED Indicator “Footswitch Activation” (Blinking blue)
Figure 4-7: Low Battery and Footswitch Activation LED(S)
Figure 4-8: Integrated IR receiver and remote IR receiver
Wireless footswitch
“Low Battery” and “Signal
transmission" LED indicators
13
12
1
2
Console IR Receivers
Receptacle for cable
of Remote IR
Receiver
