Misonix sonastar SYSTEM-M200 - Figure 7-2 Monopolar COAG Interface Schematic

Instructions for Use SonaStar Ultrasonic Surgical Aspiration System
IFU-601 Rev T March 2023 Page 51 of 73
The items needed for interfacing a SonaStar system with an approved electrosurgical device are listed below, in
Table 7-1.
Description Part Number
Fig. 7-2 Cross
Reference
Type
Umbilical Connector, Force2
or Force Fx
CFSM6
-
C140
Item 2
Reusable
Umb
ilical Connector, Conmed
CFSM6
-
C14
1
Item 2
Reusable
Um
bilical Connector, Erbe
CFSM6
-
C142
Item 2
Reusable
Umbilical connector
s for other electrosurgery units
Check with your
Misonix
distributor
Single
-
Use Monopolar Handpiece Cable, 5
-
pack
CFSM6
-
D050
Item
5
Disposable
Table 7-1: Monopolar COAG Interface Components
Figure 7-2: Monopolar COAG Interface Schematic
1. Wireless Footswitch
2. Umbilical Cable
3. Ultrasonic Generator
4. Handpiece with Cable
5. Single-use Monopolar Handpiece Cable
6. Ground Pad with Cable
7. Electrosurgical Generator
7. Ultrasonic Generator
Rear View
3. Electrosurgical
Generator
6. Ground Pad
with Cable
Handpiece
1. Wireless Footswitch
2. Umbilical Cable
4. Handpiece with Cable
5. Single-Use Monopolar Handpiece Cable
O
steo
S
culpt
tm
RFEnable
