128
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
8. Remove four rubber pads and four screws on the top of keyboard. (Figure 2-32)
9. Remove two rubber foots and two screws on the bottom of keyboard. Then detach the keyboard cover.
(Figure 2-33)
Figure 2-32 Remove two rubber pads and screws Figure 2-33 Remove two rubber foots and screws
