129
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
10. Remove three screws fastening the keyboard board and ground cord. Disconnect one cable from the keyboard
board. (Figure 2-34)
11. Disconnect the cable from the keyboard board. Then remove the keyboard board. (Figure 2-35)
Figure 2-34 Remove two screws and one
disconnect one cable
Figure 2-35 Disconnect the cable to remove the
keyboard board
