MiTAC E-8590 - Page 172

171
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
******Reset Circuit Checking(2)******
+3VS
SB_PWRGD
from page 27
IDE_RESET
+5VS
R367
10K
Q23
DTC144WK
14
7
13
12
+3VS
U9F
74AHC14_V
U6
CB710
R84
0
U14
VT6306
PCI_1394_RESET#
P13
P15
J21
PCI32-SLOT
PCI_SLOT_RESET#
U27
VT1211
LPC_SPIO_RESET#
P12
U5
VT8703
PCI_NB_RESET#
PCIRST#
D4
BAW56
R118
4.7K
IDE_RESET#
IDE_RESET#
P21
J23
First IDE
J18
Secondary IDE
1
5
1
3
11
10
14
7
+3VS
U9E
74AHC14_V
P4P24
U18
VT8235_7
P10
X5
32.768KHZ
CM200
C337
15P
C338
20P
RTCX2
RTCX1
U9D
74AHC14_V
14
7
9
8
+3VS
POWER_ON_RESET#
CARD_RESET#
8.2 No Display (System Failure)
28
A15
92 175166
SB_PWRGD
From page 27
NB_CPU_Reset#
To page2
