Defines Integrated Solutions for Mobile PC Designs
High performance SMA VT8703 North Bridge: Integrated Pentium 4 VIA DDR North Bridge and S3 Graphics
Savage4 2D/3D AGP 4x Graphics Controller in a single chip
64-bit Advanced ECC Memory controller supporting PC2100/PC1600 DDR and PC100/PC133 SDR SDRAM
Combines with VIA VT8233 V-Link South Bridge for integrated LAN, Audio, ATA100 IDE, and 6 USB ports
2.5V Core and AGTL+ I/O
37.5 x 37.5mm PBGA package with 664 balls
High Performance CPU Interface
Support for Intel™ Pentium 4 processors with 400 MHz (100 MHz QDR) CPU Front Side Bus (FSB)
Built-in Phase Lock Loop circuitry for optimal skew control within and between clocking regions
Nine outstanding transactions (eight In-Order Queue (IOQ) plus one output latch)
Dynamic deferred transaction support
High Bandwidth 266MB/S 8-bit V-Link Host Controller
Supports 66MHz V-Link Host interface with peak bandwidth of 266MB/S
Operates at 2X or 4X modes
Full duplex commands with separate command / strobe
