201
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
Part Number Description Location
291000021101 CON;HDR,MA,11P*1,1.25,R/A,DF13-1 J1
291000011101 CON;HDR,MA,11P*1,1.25,ST,SMT J1
291000024410 CON;HDR,MA,22P *2,2MM,H4.99,R/A,S J502
291000020206 CON;HDR,MA,2P*1,1.25MM,H2.57,R/A J509,J6
291000020206 CON;HDR,MA,2P*1,1.25MM,H2.57,R/A J502
291000010209 CON;HDR,MA,2P*1,1.25MM,H4.2,ST ,S J505
291000000203 CON;HDR,MA,2P*1,3.5MM,R/A,SMT,SM J2
331040060010 CON;HDR,MA,30P*2,G462-9111-601,S J4
291000010303 CON;HDR,MA,3P*1,1.25MM,H4.2,ST ,S J501
331040014007 CON;HDR,MA,7P*2,G462-9718-141,SP J1
291000256818 CON;IC CARD,68P,.635MM,JC21-BRB2 J507
291000256820 CON;IC CARD,68P,.635MM,JC21EJ-DR
331870004010 CON;MINI DIN,4P,R/A,W/GROUND,C10 J516
331810006044 CON;P HONE JACK,6P2C,H11.5,RJ11,T J506
291000810806 CON;P HONE JACK,8P8C,SMD,RJ45 J504
331910002006 CON;POWER JACK,2P,20VDC,5A,DIP PJ501
331840005007 CON;STEREO JACK,5P,R/A,W9.1,LGY2 J510,J511,J514
331000008033 CON;USB,FM,H15.64,R/A,4P*2,2522A J503,J504
346670000005 CONDUCTIVE SHEET; LCD,CONN,7521
342503200003 CONTACT P LATE;W4L18T0.15,7521/GR
342503100004 CONTACT PLATE;W4L27,1/2R,1/2T,75
342502900001 CONTACT PLATE;W4L27T0.15,7068
342503100002 CONTACT PLATE;W4L63,1/2R,1/4T,75
342503200201 CONTACT PLATE;W5L35T0.15,WEASEL,
342503400002 CONTACT PLATE;W5L9T 0.13,7170LI,P
Part Number Description Location
340673500013 COVER ASSY;HEATSINK,WEASEL
340673500002 COVER ASSY;K/B,WEASEL
340673500004 COVER ASSY;LCD,WEASEL
441673510031 COVER ASSY;M/B-AMD,256M,EOS,XP,W
340673500001 COVER ASSY;WEASEL
344673500009 COVER;BATTERY,WEASEL
344673500003 COVER;DIMM,WEASEL
344673500002 COVER;HDD,WEASEL
344673500013 COVER;HINGE,WEASEL
272625470401 CP;47P*4 ,8P,50V ,10%,1206,NPO,S CP1,CP501,CP502,CP503
346600000142 DIALAMY;T=0.1,W=113,WHITE,PRC
291006214434 DIMM SOCKET;144P,.8MM,H5.2,SPEED J503
288110355001 DIODE;1SS355,80V,100mA,SOD-23,SM PD3
288100032013 DIODE;BAS32L,VRRM75V,MELF,SOD-80 PD5,PD6
288100032013 DIODE;BAS32L,VRRM75V,MELF,SOD-80 PD4
288100054004 DIODE;BAT54C,SCHOTTKY DIODE,Low - D501
288100701002 DIODE;BAV70LT1,70V,225MW,SOT-23 D25,D505
288100701002 DIODE;BAV70LT1,70V,225MW,SOT-23 PD10,PD8
288100099001 DIODE;BAV99,70V,450MA,SOT-23 D12,D13
288100099001 DIODE;BAV99,70V,450MA,SOT-23 PD2,PD3
288100099001 DIODE;BAV99,70V,450MA,SOT-23 D1
288100056003 DIODE;BAW56,70V,215mA,SOT-23 D507,D510
288105230004 DIODE;BZM55B3V6,ZENER,3.6V,5mA,M ZD1
288100202001 DIODE;DAN202K,80V,SWITCH,SMT D18,D20,D506
288101004024 DIODE;EC10QS04,RECT,40V,1A,CHIP, PD503
9. Spare Parts List -3
